Vibratory Driving of Pipe (Tubular Sheet Pile)
Vibratory driving of pipes and tubular sheet piles for retaining structures, excavation support, and bank protection structures.
-
>50
Units of own equipment
-
>150
Qualified employees
-
2
Production bases in Moscow and Saint Petersburg
-
200+
Civil and industrial construction projects
About the Technology
Vibratory driving of pipes is used for the installation of sheet pile enclosures, tubular sheet pile walls, and temporary and permanent retaining structures. Tubular sheet piles are used where increased stiffness of the enclosure is required, where there are high lateral loads, or where the structure must be installed in difficult soil conditions.
Driving is performed using a vibratory hammer, which transmits directed vibrations to the pipe and reduces soil resistance. Before starting work, the design elevations, geology, pipe diameter and length, interlock connection layout, equipment access, and site constraints are checked. Control is maintained over pipe position, driving depth, and compliance with the design axis.
- Analysis of the project and soil conditions - we check the design solutions, geology, driving depth, pipe diameter, and requirements for the tubular sheet pile wall.
- Selection of equipment and accessories - we determine the type of vibratory hammer, base machine, clamps, guides, and auxiliary equipment.
- Site preparation - we organize the work zone, equipment access, pipe storage, geodetic layout, and control marks.
- Driving of the pipe or tubular sheet pile - we perform vibratory driving with control of verticality, depth, plan position, and the condition of interlock connections.
- Acceptance of completed work - we record actual elevations, verify compliance with the design, and hand over the result for the next stages of construction.
Advantages
-
High stiffness of the retaining structure
-
Ability to work with high lateral loads
-
Suitable for excavation pits, coastal, and hydraulic engineering facilities
-
Faster driving compared to a number of alternative methods
-
Can be used in difficult soil and confined conditions
-
We will Calculate the Cost of Works
Leave your contacts, and our engineer will prepare a preliminary calculation for you
Price
Стоимость услуги вибропогружения трубошпунта не является фиксированной и рассчитывается индивидуально под каждый объект. На итоговую цену влияют несколько ключевых факторов: диаметр и длина трубошпунта, характеристики грунта (плотность, наличие включений), глубина погружения, требуемая точность позиционирования, а также объем работ и удаленность площадки. Для получения актуальной цены необходимо подготовить техническое задание или проектную документацию — после их анализа подрядчик предложит расчет с учетом конкретных условий.
How We Work
Simple and transparent workflow
Request
Project Analysis
Solution Selection
Work Execution
Handover
Frequently Asked Questions
-
Can vibratory driving of pipes be performed without a project?
For working sheet pile enclosures, a project is mandatory. Without a project, only a preliminary assessment of the technology, equipment, and approximate budget can be carried out.
-
How does a tubular sheet pile differ from a regular Larsen sheet pile?
A tubular sheet pile has higher stiffness due to the round steel pipe. It is used where a standard sheet pile profile is insufficient in terms of loads or structural operating conditions.
-
Can the work be carried out in winter?
Yes, vibratory driving of pipes is possible in winter. Restrictions depend on site conditions, soil freezing, equipment access, and project requirements.
-
How is driving accuracy controlled?
The position of pipes is controlled according to the geodetic layout, design axis, verticality, and actual driving elevation. If necessary, guides and additional measures are used to maintain the design position.
Why Choose Us
-
Own fleet of equipment
We select vibratory hammers and base machines according to pipe parameters, soil conditions, and site requirements.
-
Experience in tubular sheet pile works
We work with excavation enclosures, hydraulic engineering, and industrial facilities.
-
Engineering preparation
Before mobilizing to the site, we verify the project, geology, technology, and site constraints.
-
Control of pipe position
We monitor verticality, elevations, and compliance of the tubular sheet pile wall with the project.
-
Work in difficult conditions
We can perform driving in confined areas, on operating facilities, and under complex logistics conditions.
-
